Aruba Instant On AP22 Wi-Fi 6 Indoor Access Point

Weight

1.1 lb

Dimension (H x W x D)

1.5 x 6.3 x 6.3 in

Optical Drive Type

None

Compliant Standards

IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, Wi-Fi CERTIFIED 6

Connectivity Technology

Wireless

Data Link Protocols

Bluetooth, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

Features

Advanced Cellular Coexistence (ACC), Bluetooth (BLE) clients support, BSS Coloring, Firewall protection, Low Density Parity Check (LDPC), Manageable, MU-MIMO technology, Orthogonal Frequency Division Multiple Access (OFDMA), PPPoE server, Reset button, Security lock slot (cable lock sold separately), Smart Mesh technology, Static IP mode, Target Wait Time (TWT), Transmit Beam-forming (TxBF) ready, Trusted Platform Module (TPM), Wall mountable

Form Factor

Wall / ceiling mountable

Network Band

2.4 GHz, 5 GHz

Power Over Ethernet (PoE)

PoE

Product Type

Wireless access point

Status Indicators

Status

Wireless LAN

802.11a/b/g/n/ac, Bluetooth

Interface Provided

1 x - RJ-45

Operating System

Instant On

Antenna Form Factor

Internal

Antenna Gain Level

3 DBi

Directivity

Omni-directional

Encryption

WPA2, WPA3

Max Operating Temperature

104-degree Fahrenheit

Min Operating Temperature

32-degree Fahrenheit

MTBF

91 years

IoT Communications Technology

Bluetooth Low Energy (LE)

Ruggedized Design

Indoor

Service Activation

No

Network Device

Concurrent data rate (2.4 GHz): 574 Mbps, Concurrent data rate (5 GHz): 1.2 Gbps
