Benq Board Pro RP8605 86" 4K UHD Interactive Flat Panel Display
Exclusive of all taxes
Product Details
Key Features
Ultra‑High 4K UHD Resolution: The 86" panel delivers crystal‑clear 3840 × 2160 pixels for detailed visuals in classrooms and conference rooms.
Fast Picture Response: Picture response time under <8 ms ensures smooth motion without ghosting, ideal for video playback and interactive demos.
Vibrant Color Accuracy: 10‑bit color depth covering 72% NTSC provides rich, lifelike colors for design and media creation.
High Brightness & Contrast: 450 nits brightness and a contrast ratio of 1200:1 (typical) up to 50000:1 dynamic delivers clear images even in bright environments.
Responsive Multi‑Touch: Supports up to 50 touch points with Ultra Precision IR and a touch response time of <2.5 ms for seamless collaboration.
Powerful Compute Engine: Equipped with MTK Genio 720 CPU (2x Cortex‑A78 + 6x Cortex‑A55), Mali‑G57 MC2 GPU, 16GB DDR5 RAM, 256GB storage and a 10 TOPS NPU for AI‑enhanced applications.
Extensive Connectivity: Features 5 HDMI ports, VGA, multiple USB‑C/USB‑A/B, Ethernet, Wi‑Fi 6, Bluetooth 5.2, DP 1.2a and RS232 for versatile peripheral integration.
Built‑In Audio: Integrated 2×25 W speakers with subwoofer deliver clear sound without external speakers.
Robust Build and Mounting: VESA 800×600 mm pattern and a sturdy 55 kg chassis ensure stable installation on walls or stands.
Energy Efficient Operation: Typical power consumption of 126.4 W with standby power under 0.5 W meets green office standards.
Native Resolution | 4K UHD (3840 × 2160) pixels |
Panel Type | IPS |
Aspect Ratio | 16:9 |
Picture Response Time | <8 ms |
Display Colors | 10-bit 72% NTSC |
Brightness (typical) | 450 nits |
Contrast Ratio | 1200:1 (typical), 50000:1 (Dynamic) |
Viewing Angle | 178° / 178° |
Life Time | 50,000 hours |
Display Orientation | Landscape |
Touch Point | up to 50 |
Touch Tool | Ultra Precision IR |
Touch Response Time | < 2.5 ms |
Operating System Version | Android 15.0 EDLAC |
CPU | MTK Genio 720: 2x Arm Cortex-A78, 6x Arm Cortex-A55 |
GPU | Arm Mali-G57 MC2 |
RAM | 16GB DDR5 |
ROM | 256GB |
NPU | Built in 10 TOPS NPU |
HDMI Ports | 4 × HDMI 2.0, 1 × HDMI 2.0 |
VGA Input | 1 x VGA Input |
Audio In | 1 x Audio In |
Audio Out (Earphone) | 1 x Earphone |
Ethernet LAN | 2x Ethernet |
USB-C (DP Alt Mode) | 1x USB-C 3.0/3.1/3.2 Gen 1 with DP Alt Mode |
USB-A 3.0 | 5x USB-A 3.0/3.1/3.2 Gen 1 |
USB-B 3.0 | 3x USB-B 3.0/3.1/3.2 Gen 1 |
USB-A 2.0 | 1x USB-A 2.0 |
USB-C 2.0 | 1x USB-C 2.0 |
USB-C 3.0 (Audio/Photo/Video) | 2x USB-C 3.0/3.1/3.2 Gen 1 [Audio/Photo/Video] |
RS232 | 1x RS232 |
Wi-Fi | Wi-Fi 6 |
Bluetooth | Bluetooth 5.2 |
DP | 1 x DP 1.2a |
Built-In Speakers | Yes, 2x 25 W / Subwoofer |
Active Screen Size | 86" |
Dimensions | 77 x 47.3 x 5.1" / 1955.8 x 1201.4 x 129.5 mm |
Weight | 121.3 lb / 55 kg |
Power Input | AC 100-240V 50/60Hz |
Standby Power | <0.5 W |
Power Requirements (Typical) | 126.4 W |
Power Requirements (Standby) | < 0.5 W |
VESA Mount | 800 × 600 mm (4 × M8 × 25L) |
Warranty | 3 Years |
Description
Benq Board Pro RP8605 86" 4K UHD Interactive Flat Panel Display
Key Features & Benefits:
- Ultra‑High 4K UHD Resolution: The 86" panel delivers crystal‑clear 3840 × 2160 pixels for detailed visuals in classrooms and conference rooms.
- Fast Picture Response: Picture response time under <8 ms ensures smooth motion without ghosting, ideal for video playback and interactive demos.
- Vibrant Color Accuracy: 10‑bit color depth covering 72% NTSC provides rich, lifelike colors for design and media creation.
- High Brightness & Contrast: 450 nits brightness and a contrast ratio of 1200:1 (typical) up to 50000:1 dynamic delivers clear images even in bright environments.
- Responsive Multi‑Touch: Supports up to 50 touch points with Ultra Precision IR and a touch response time of <2.5 ms for seamless collaboration.
- Powerful Compute Engine: Equipped with MTK Genio 720 CPU (2x Cortex‑A78 + 6x Cortex‑A55), Mali‑G57 MC2 GPU, 16GB DDR5 RAM, 256GB storage and a 10 TOPS NPU for AI‑enhanced applications.
- Extensive Connectivity: Features 5 HDMI ports, VGA, multiple USB‑C/USB‑A/B, Ethernet, Wi‑Fi 6, Bluetooth 5.2, DP 1.2a and RS232 for versatile peripheral integration.
- Built‑In Audio: Integrated 2×25 W speakers with subwoofer deliver clear sound without external speakers.
- Robust Build and Mounting: VESA 800×600 mm pattern and a sturdy 55 kg chassis ensure stable installation on walls or stands.
- Energy Efficient Operation: Typical power consumption of 126.4 W with standby power under 0.5 W meets green office standards.
Ideal For:
- University lecture halls and classrooms
- Corporate boardrooms and meeting rooms
- Digital signage and retail display zones
- Design studios and creative agencies
- Healthcare facilities for tele‑medicine and training
- Government training centers
- Remote learning and e‑learning platforms
Summary:
The BenQ Board Pro RP8605 86" 4K UHD Interactive Flat Panel combines a stunning 3840×2160 display, ultra‑fast touch response and powerful MTK Genio 720 compute hardware, making it perfect for education, enterprise and digital signage. With 50 touch points, 10‑bit color, 450 nits brightness and built‑in 2×25 W speakers, it delivers immersive, collaborative experiences. Its extensive connectivity—including HDMI, USB‑C with DP Alt Mode, Wi‑Fi 6 and Bluetooth 5.2—covers all peripheral needs. Available now at Revolution Technology BD with a 3‑year warranty.
