Product Details
Key Features
Form Factor: 1U Rack Server
Processors: Dual Intel Xeon E5-2680v4
Memory: 32GB DDR4 (24 DIMM slots, 2400MT/s)
Storage: Up to 24x 1.8" or 10x 2.5" hot-plug
drives (SAS/SATA/SSD/NVMe)
RAID: PERC H330/H730/H730P controllers
Networking: 4x 1Gb or 4x 10Gb embedded NIC
Power: 495W-1100W hot-plug PSUs
Management: iDRAC8 with Lifecycle Controller
Expansion: 3x PCIe 3.0 slots
Specification
|
Form
Factor |
1U Rack
Server |
|
Dimensions
(H x W x D) |
4.28 cm x
48.23 cm x 70.05 cm - 75.51 cm (1.68 in x 18.98 in x 27.57 in - 29.72 in) |
|
Processor |
Intel® Xeon
E5-2680v4 product family |
|
Processor
Sockets |
2 |
|
Memory |
32GB DDR4
(24 DIMM slots), 2400MT/s |
|
Drive Bays |
Configurations
for up to 24x 1.8", 10x 2.5", or 8x 2.5" hot-plug drives (SAS,
SATA, SSD, NVMe) |
|
Maximum
Internal Storage |
600GB, Up
to 23TB |
|
RAID
Controllers |
PERC S130,
H330, H730, H730P (Internal); PERC H830 (External) |
|
Embedded
NIC |
4 x 1Gb,
or 2 x 1Gb + 2 x 10Gb, or 4 x 10Gb |
|
Power
Supplies |
495W,
750W, 1100W (AC Platinum); 750W (AC Titanium); 1100W (DC) |
|
I/O Slots |
Up to 3 x
PCIe 3.0 slots plus dedicated PERC slot |
|
Remote
Management |
iDRAC8
with Lifecycle Controller (Express default, Enterprise upgrade) |
|
Warranty |
1 Year Warranty |
This is a highly configurable and scalable 1U rack server
from Dell's 13th generation (Xeon E5-2680v4), supporting two processors, large
amounts of DDR4 memory, and extensive flexible storage options. It is designed
for high availability in data centers with features like hot-plug power and
cooling, advanced RAID, and the iDRAC8 remote management system.
