MikroTik Cloud Smart Switch CSS610-8G-2S+IN

Genuine Product Fast Delivery Easy Returns

Key Features

Smart Switch for Large Networks: The MikroTik Cloud Smart Switch CSS610-8G-2S+IN is ideal for large networks that require high-speed data transfer and efficient management. With 8 10/100/1000 Ethernet ports and 2 SFP+ ports, this switch can handle a high volume of traffic.

Easy Management with SwitchOS Lite: The SwitchOS Lite operating system makes it easy to manage and configure the switch, even for those without extensive networking experience. With a user-friendly interface, you can quickly set up and monitor your network.

Power Efficiency with Passive PoE: The CSS610-8G-2S+IN features passive PoE, which provides power to devices over the Ethernet cable, eliminating the need for separate power cords. This makes it ideal for installations where space is limited.

High MTBF for Reliable Operation: With an MTBF of approximately 200,000 hours at 25°C, the MikroTik Cloud Smart Switch CSS610-8G-2S+IN is designed to provide reliable operation over an extended period.

Wide Operating Temperature Range: The switch can operate in temperatures ranging from -20°C to 60°C, making it suitable for use in a variety of environments.

Compliance with International Standards: The CSS610-8G-2S+IN meets the requirements of CE, EAC, and ROHS certifications, ensuring compliance with international standards for safety and environmental sustainability.

Compact Design for Space-Constrained Installations: The switch's compact dimensions of 200 x 164 x 44 mm make it ideal for installations where space is limited.

High-Speed Data Transfer with 10/100/1000 Ethernet Ports: The 8 10/100/1000 Ethernet ports on the CSS610-8G-2S+IN enable high-speed data transfer, making it suitable for applications that require fast and reliable connectivity.

Future-Proof with SFP+ Ports: The 2 SFP+ ports on the switch provide future-proof connectivity, allowing you to upgrade your network infrastructure as needed.

Specification

Product code	CSS610-8G-2S+IN
Switch chip model	88E6193X
Dimensions	200 x 164 x 44 mm
Operating System	SwitchOS Lite
Storage size	64 KB
Storage type	FLASH
MTBF	Approximately 200'000 hours at 25C
Tested ambient temperature	-20°C to 60°C
Powering	Number of DC inputs
Number of DC inputs	2
DC jack input Voltage	12-57 V
Max power consumption	11 W
Max power consumption without attachments	5 W
PoE in	Passive PoE
PoE in input Voltage	12-57 V
Ethernet	10/100/1000 Ethernet ports
Number of Ethernet ports	8
Fiber	SFP+ ports
Number of SFP+ ports	2
Certification & Approvals	CE, EAC, ROHS
IP	IP20

Description

MikroTik Cloud Smart Switch CSS610-8G-2S+IN

Key Features & Benefits:

Smart Switch for Large Networks: The MikroTik Cloud Smart Switch CSS610-8G-2S+IN is ideal for large networks that require high-speed data transfer and efficient management. With 8 10/100/1000 Ethernet ports and 2 SFP+ ports, this switch can handle a high volume of traffic.
Easy Management with SwitchOS Lite: The SwitchOS Lite operating system makes it easy to manage and configure the switch, even for those without extensive networking experience. With a user-friendly interface, you can quickly set up and monitor your network.
Power Efficiency with Passive PoE: The CSS610-8G-2S+IN features passive PoE, which provides power to devices over the Ethernet cable, eliminating the need for separate power cords. This makes it ideal for installations where space is limited.
High MTBF for Reliable Operation: With an MTBF of approximately 200,000 hours at 25°C, the MikroTik Cloud Smart Switch CSS610-8G-2S+IN is designed to provide reliable operation over an extended period.
Wide Operating Temperature Range: The switch can operate in temperatures ranging from -20°C to 60°C, making it suitable for use in a variety of environments.
Compliance with International Standards: The CSS610-8G-2S+IN meets the requirements of CE, EAC, and ROHS certifications, ensuring compliance with international standards for safety and environmental sustainability.
Compact Design for Space-Constrained Installations: The switch's compact dimensions of 200 x 164 x 44 mm make it ideal for installations where space is limited.
High-Speed Data Transfer with 10/100/1000 Ethernet Ports: The 8 10/100/1000 Ethernet ports on the CSS610-8G-2S+IN enable high-speed data transfer, making it suitable for applications that require fast and reliable connectivity.
Future-Proof with SFP+ Ports: The 2 SFP+ ports on the switch provide future-proof connectivity, allowing you to upgrade your network infrastructure as needed.

Ideal For:

Large network administrators
Data centers
Enterprise networks
Service providers
Network engineers
IT professionals
Businesses with high-speed data transfer requirements

Summary:

The MikroTik Cloud Smart Switch CSS610-8G-2S+IN is a high-performance switch designed for large networks and data centers. With 8 10/100/1000 Ethernet ports and 2 SFP+ ports, this switch provides high-speed data transfer and efficient management. The SwitchOS Lite operating system makes it easy to manage and configure the switch, while the passive PoE feature provides power efficiency. Available at Revolution Technology BD, this switch is ideal for businesses with high-speed data transfer requirements.
