Netgear MS510TXUP 4-Port 1G/2.5G PoE++(UPoE) + 4-Port 1G/2.5G/5G/10G PoE+ + 2-Port SFP+ Smart Managed Rackmount Switch
Contact us for pricing
Product Details
Key
Features
Model: MS510TXUP
Ports: 4 ports 1G/2.5G
4 ports multi-gig/10G with 2
dedicated 10 Gigabit fiber ports for WiFi 6
Buffer size: 16Mbit
Specification
Specification
|
Multi-gigabit copper ports |
4
(1G/2.5G) |
|
Multi-gigabit/10 Gigabit copper ports |
4
(1G/2.5G/5G/10G) |
|
SFP+ ports |
2 |
|
Number of PoE++ (802.3bt) ports |
8 |
|
Total PoE Power budget |
295
Watts |
|
Uninterrupted PoE |
Yes |
|
Max MAC entries |
32K |
|
Buffer size |
16Mbit |
|
VLAN (Number Supported) |
256 |
|
VLAN routing |
Yes |
|
Dynamic VLAN assignment |
Yes |
|
MLD Snooping |
Yes |
|
Static route |
Yes
(32) |
|
Host ARP table |
512
ARP |
|
EEE |
Yes |
|
DoS Prevention |
Yes |
|
Internal/External PSU |
Internal |
|
Max power (worst case, all ports used, line-rate traffic) |
380W |
|
Fans |
3 |
|
Acoustic Noise Level @25C |
33.0
dBA |
|
Operating Temperature |
0°
to 50° C (32 to 122F) |
|
MTBF |
848,553
hrs (96.9 yrs) |
