NZXT RF-U24HF-B1: F240 RGB Core Fan (Single Frame) - Black
Contact us for pricing
Product Details
Key feature
Model:
F240 RGB Core (Single Frame) (RF-U24HF-B1)
Dimension:
240 x 120 x 26 mm
Fan
Speed: 500 - 2,400 ± 250 RPM
Airflow:
75.12 CFM
Warranty:
5-Year Brand Warranty
Specification
|
Model |
F240 RGB Core
(Single Frame) |
|
Model Number |
RF-U24HF-B1 |
|
Color |
Black |
|
Power Consumption |
12V DC, 0.56A
(6.72W) / 5V DC, 0.45A (2.25W) |
|
Bearing Type |
Fluid Dynamic
Bearing |
|
LED Output |
8 LEDs per
Fan |
|
Connector |
8-pin for PWM
& RGB |
|
Cable Length |
600 mm |
|
Material |
Plastic,
Rubber, PCB |
|
Life Expectancy |
60,000 Hours |
|
Fan Speed |
500 – 2,400
±250 RPM per fan |
|
Airflow |
75.12 CFM per
fan |
|
Static Pressure |
3.3 mmH₂O per fan |
|
Noise Level |
30 dBA per
fan |
|
Dimensions |
240 × 120 ×
26 mm |
|
Inside the Box |
1 × RGB Core
Fan, 4 × Mounting Screws, 1 × Splitter Cable |
|
Warranty |
5 Years Brand
Warranty |
Description
NZXT
F240 RGB Core 240mm Single Frame Fan - Black
NZXT
F240 RGB Core 240mm Single Frame Fan - Black is a highly effective way to cool
systems down quietly, with vivid RGB lighting in an easy-to-install design.
Having the single-frame setup already integrated, the F240 RGB Core simplifies
installation and control since one cable will be enough for all fans. Connect
it to an NZXT controller sold separately for fan speed and lighting control
with NZXT CAM software, or connect it directly to any 5V ARGB header on a
compatible motherboard with the included splitter.
The
F240 RGB Core features optimized fan blades, creating a static pressure of 3.3
mm H2O that forces air through tight spaces while achieving a commendable 75.12
CFM airflow. Equipped with fluid dynamic bearings, these fans operate at very
minimal noise and can maintain stability up to 60,000 hours of operation. In
each fan's hub is an insert of eight individually addressable RGB LEDs, which
are diffused through semi-translucent blades to shine bright, colorful visuals
to further accentuate your build.
PWM
control enables the fans to adjust their speed dynamically between 500 to 2,400
RPM according to system temperatures, providing efficient cooling with reduced
noise levels. Anti-vibration rubber corners absorb the vibration and minimize
noise from operations. With Zero RPM Mode, utilized with an NZXT controller or
NZXT motherboard, fans are allowed to come to a complete stop under light
loads, further reducing noise. Customize lighting and fan speeds with NZXT CAM
when connected to an NZXT controller. NZXT CAM also synchronizes settings
across other NZXT components. NZXT f240 RGB core: A functional air cooling
solution with customized RGB, the high-performance NZXT F240 RGB Core 240mm fan
is perfect for performance and style-focused builds.
