SAKO LI SUN 25.6V 100AH Lithium Battery
Exclusive of all taxes
Product Details
Key Features
High Capacity: The 100Ah nominal capacity delivers extended runtime for demanding applications.
Large Energy Storage: With a total energy of 2560Wh, the battery stores ample power for off‑grid use.
High Usable Energy: Provides 2304Wh usable energy at 90% depth of discharge, maximizing efficiency.
Wide Voltage Range: Operates safely between 22.4V and 29.2V, ensuring stable performance under load.
Fast Charging: Fast charge voltage of 28.8V reduces charging time while protecting cell health.
Robust Discharge Capability: Supports 100A continuous and 150A pulse discharge (1 sec) for high‑power bursts.
Long Cycle Life: Exceeds 6000 cycles at 25°C, offering years of reliable service.
Smart Communication: Integrated RS485 interface enables real‑time monitoring and control.
Broad Temperature Tolerance: Operates from 10°C to 50°C, suitable for diverse climates.
Durable Construction: IP20 rating protects against dust and accidental contact in indoor installations.
Battery Type | LiFePO4 (Lithium Iron Phosphate) |
Nominal Voltage | 25.6V |
Nominal Capacity | 100Ah |
Total Energy | 2560Wh |
Usable Energy (90% DOD) | 2304Wh |
Voltage Range | 22.4V–29.2V |
Fast Charge Voltage | 28.8V |
Float Charge Voltage | 28.0V |
Low DC Cut-off Voltage | 23.4V |
Max Continuous Discharge Current | 100A |
Max Pulse Discharge Current | 150A (1Sec) |
Max Charge Current | 50A |
Cycle Life | >6000 cycles @25°C (0.5C, 90% DOD, 60% EOL) |
Communication | RS485 |
Storage Temperature | 0°C–30°C |
Working Temperature | 10°C–50°C |
IP Rating | IP20 |
Description
SAKO LI SUN 25.6V 100AH Lithium Battery
Key Features & Benefits:
- High Capacity: The 100Ah nominal capacity delivers extended runtime for demanding applications.
- Large Energy Storage: With a total energy of 2560Wh, the battery stores ample power for off‑grid use.
- High Usable Energy: Provides 2304Wh usable energy at 90% depth of discharge, maximizing efficiency.
- Wide Voltage Range: Operates safely between 22.4V and 29.2V, ensuring stable performance under load.
- Fast Charging: Fast charge voltage of 28.8V reduces charging time while protecting cell health.
- Robust Discharge Capability: Supports 100A continuous and 150A pulse discharge (1 sec) for high‑power bursts.
- Long Cycle Life: Exceeds 6000 cycles at 25°C, offering years of reliable service.
- Smart Communication: Integrated RS485 interface enables real‑time monitoring and control.
- Broad Temperature Tolerance: Operates from 10°C to 50°C, suitable for diverse climates.
- Durable Construction: IP20 rating protects against dust and accidental contact in indoor installations.
Ideal For:
- Solar home systems in rural Bangladesh
- Off‑grid cabins and tiny houses
- Electric vehicle conversion projects
- Marine and boat power backup
- Telecom tower backup power
- Rural microgrid storage solutions
- Emergency power for clinics and hospitals
Summary:
The SAKO LI SUN 25.6V 100AH Lithium Battery delivers 2560Wh of total energy with 2304Wh usable at 90% DOD, making it ideal for off‑grid and backup power needs. Its robust LiFePO4 chemistry offers over 6000 cycles, fast charging at 28.8V, and high discharge currents up to 150A pulse. Equipped with RS485 communication and a wide operating temperature range, it suits solar systems, EV conversions, marine, and telecom applications. Available now at Revolution Technology BD for reliable, long‑lasting power solutions.
