V-SOL V1016-2G-S-P Unmanaged PoE Switch
Contact us for pricing
Product Details
Key Features
High-performance V1016-2G-S-P Ethernet Switch designed for stable business networking.
Supports 6.84 Mbps data transfer rate for smooth and reliable communication.
Powerful 9.2 Gbps switching capacity ensures fast packet forwarding and low latency.
Built-in 2K MAC address table for efficient traffic management and device recognition.
Ideal for small to medium networks, offices, CCTV systems, and enterprise setups.
Durable hardware design for 24/7 continuous operation.
Plug-and-play installation with no complex configuration required.
Energy-efficient architecture helps reduce power consumption.
Optimized for high-speed LAN connectivity and network expansion.
Specification
|
Specification |
Details |
|
Model |
V1016-2G-S-P |
|
Type |
Undamaged PoE Switch |
|
Certification |
EMI: FCC
Part 15, CISPR (EN55032) Class A |
|
Dimensions (L × W × H) |
200 × 118 × 44 mm |
|
Operating Temperature |
-10 °C to 50 °C |
|
Operating Humidity |
10%–90% non-condensing |
|
Storage Temperature |
-40 °C to 70 °C |
|
Storage Humidity |
5%–90% non-condensing |
|
Fan |
Fan-less |
|
MAC Address Table |
2K |
|
Memory |
3 M |
|
Network Standards |
IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x |
|
MTBF |
100,000 hours |
|
Jumbo Frame |
9 Bytes |
|
Chassis |
Metal |
|
PoE Standards |
IEEE 802.3af (15.4 W), IEEE 802.3at (30 W) |
|
Ports |
16 × FE
PoE RJ45 |
|
Power Input |
AC 100–240 V |
|
Power Supply |
DC 52 V / 5.76 A |
|
Total Power Consumption |
Approx. 300 W |
|
Transmission Method |
Store and Forward |
|
Weight |
2.15 kg (empty) |
Description
V-SOL V1016-2G-S-P Po E Switch
The V-SOL V1016-2G-S-P1 Unmanaged PoE Switch is a reliable and easy-to-use networking solution designed for small to medium PoE deployments such as IP surveillance, wireless access points, and office networks. The V1016-2G-S-P1 features 16 Fast Ethernet PoE ports that deliver both power and data through a single Ethernet cable, along with 2 Gigabit Ethernet uplink ports and 1 Gigabit SFP uplink to ensure stable, high-speed connections to core networks or fiber backbones. Supporting IEEE 802.3af/at PoE standards, the switch can safely power compatible devices while maintaining consistent data transmission. Its unmanaged, plug-and-play design requires no configuration, making installation quick and hassle-free. Built with a fanless, compact metal housing, the V1016-2G-S-P1 operates quietly and efficiently, offering dependable performance and long-term stability for cost-effective PoE networking needsHow to Order
