Zebra ZD230 4-Inch Value Desktop Printer
Exclusive of all taxes
Product Details
Key Features
Resolution: 203dpi (8dots/mm)
Max. Print Width: 4.09 Inches
Max. Print Length 39 inches
Maximum Print Speed: 6 Inch
per sec
Warranty: 1 year Service
Specification
|
Dimension (Thermal Transfer) |
267 mm L x 197 mm W
x 191 mm H |
|
Dimension (Direct
Thermal) |
220 mm L x 176 mm W
x 151 mm H |
|
Weight |
2.5 lbs / 1.1 kg |
|
Resolution |
203 dpi / 8 dots per
mm |
|
Memory |
256 MB Flash; 128 MB
SDRAM |
|
Maximum Print Width |
4.09 in. / 104 mm |
|
Maximum Print Speed |
6 in. / 152 mm per
second |
|
Media Sensors |
Movable black mark
sensor, Fixed off-center gap sensor |
|
Firmware |
ZPL II; EPL 2; XML |
|
Maximum Label Length |
39.0 in. / 991 mm |
|
Media Width |
1.00 in. / 25.4 mm
to 4.4 in. / 112 mm |
|
Media Roll Size |
5.00 in. / 127 mm
outer diameter |
|
Media Core Size |
0.5 in. (12.7 mm)
and 1.0 in. (25.4 mm) standard, 1.5 in. (38.1 mm) |
|
Media Thickness |
0.003 in. (0.08 mm)
min.; 0.0075 in. (.1905 mm) max. |
|
Media Types |
Roll-fed, fan-fold,
die cut, continuous, tag stock, receipt paper, wristbands |
|
Ribbon Outside
Diameter |
2.6 in. / 66 mm (300
m); 1.34 in. / 34 mm (74 m) |
|
Maximum Ribbon
Length |
984 ft. (300 m) |
|
Ribbon Ratio |
1:4 media to ribbon
(300 m); 1:1 (74 m) |
|
Ribbon Width |
1.33 in. / 33.8 mm ~
4.3 in. / 109.2 mm |
|
Ribbon Core I.D. |
1 in. / 25.4 mm (300
m); 0.5 in. / 12.7 mm (74 m) |
Description
Zebra ZD230 4-Inch Value Desktop Printer
This versatile desktop printer
is a workhorse solution for creating high-quality labels, barcodes, tags, and
wristbands. Engineered for daily use in offices, warehouses, and retail
environments, it offers the flexibility of both Direct Thermal (no ribbon
needed) and Thermal Transfer (using a ribbon for maximum durability) printing
methods. This ensures your labels remain scannable and legible, whether for
short-term shipping or long-term asset tracking.
Key Features & Benefits:
- Dual Printing Technology: Switch between Direct
Thermal for cost-effective, everyday labels and Thermal
Transfer to produce smudge- and scratch-resistant labels that
withstand heat, sunlight, and abrasion, perfect for permanent asset tags
and outdoor use.
- Fast and Efficient Performance: With a print speed of up to 6
inches per second, this printer efficiently handles medium to
high-volume printing tasks, boosting productivity and reducing wait times
for your labeling needs.
- Wide Compatibility and Easy Integration: Supports a broad range of media,
from narrow 1-inch barcode labels to wide 4.4-inch tags, including
die-cut, continuous, and even receipt paper. With ZPL II, EPL 2,
and XML firmware support, it integrates seamlessly into existing
systems.
- Robust and User-Friendly Design: Equipped with substantial memory
(256 MB Flash, 128 MB SDRAM) for complex label formats and features
movable media sensors for easy setup. Its compact footprint saves valuable
desk or counter space.
Ideal For:
- Shipping & Receiving Departments
- Retail Price and Shelf Tag Printing
- Asset Tracking and Inventory Management
- Healthcare (Patient ID Wristbands)
Summary:
This printer is a reliable, all-in-one labeling solution that balances speed,
versatility, and print quality. It is built to deliver consistent performance
for a wide array of business applications, making it an essential tool for any
organization that depends on accurate and professional labeling.
