LifeSmart Dimmer & Motion Sensor Switch
Contact us for pricing
Product Details
Multiple ways of lighting adjustment
Automatically switch on and off by human
motion detection
Precise brightness control by percentage
Product Description
Customize your own brightness with motion detection
Dimmer & Motion Sensor Switch integrates light control, motion detection, illuminance detection together into one device. It triggers light ON/OFF by detecting motion and illuminance, so it may realize light ON when people coming, light ON when getting dark and many other smart control scenes.
Specification
|
Model Number |
LS174 / LS154
(Japan) |
|
Product Type |
Wall mount
switch |
|
Wiring |
Live+neutral |
|
Control Unit |
The triac
control unit(one way) |
|
Compatible
Lights |
Filament,
halogen, LED lamp or other lamps with Triac control |
|
Operating
Temperature |
-5~45°C |
|
Operating
Humidity |
5~90% |
|
Power Supply |
AC 100-240V
50/60Hz |
|
Static
Consumption |
<1W |
|
Maximum
Overload |
Resistive
load: 250W Inductive/Capacitive
load: 200W |
|
Button |
Dimmer
button(Pressable), pairing & matching button, safety button |
|
Indicator |
Dimmer
indicator light |
|
Motion
Detection |
Yes (embedded
motion sensor) |
|
Light
Detection |
Yes (embedded
light sensor) |
|
Radio
Protocol |
CoSS |
|
Signal
Range(Open Field) |
100m |
|
Color |
Ivory white |
|
Dimension |
120*70*47mm
(with dimmer button), 68*40*27mm (flush-mount) |
|
Weight |
110g |
|
Casing |
Bottom cover:
PC, others: ABS+PC |
