GS-6311-16S8C4XR 16-Port 10/100/1000T 802.3at PoE + 2-Port 1000X SFP Gigabit Ethernet Switch

Genuine Product Fast Delivery Easy Returns

Key Features

High-Performance Network Switch: The Safenet 16-Port 10/100/1000T 802.3at PoE + 2-Port 1000X SFP Gigabit Ethernet Switch is designed for business and surveillance environments, providing high-speed data transfer and power delivery to devices.

16 Gigabit PoE+ Ports: The switch features 16 Gigabit PoE+ ports that can deliver both data and power to devices like IP cameras, access points, and VoIP phones.

2 SFP Uplink Slots: The switch also has 2 SFP uplink slots for high-speed fiber connectivity and network expansion.

Selectable Operation Mode: The DIP switch allows for selectable operation mode: Standard, VLAN, Extend.

Metal Enclosure: The switch has a metal enclosure for durability and heat dissipation.

High Power Budget: The switch has a high power budget of 250 watts, making it suitable for demanding applications.

IEEE 802.3at PoE+ Compliance: The switch is compliant with IEEE 802.3at PoE+, backward compatible with IEEE 802.3af.

6KV Surge Protection: The switch has 6KV surge protection and 8KV ESD protection for reliable operation.

Easy Installation: The switch has a simple installation process, with a user-friendly interface and clear LED indicators.

Wide Operating Temperature: The switch can operate in a wide temperature range of 0 ~ 50°C, making it suitable for various environments.

Compact Design: The switch has a compact design, making it suitable for small spaces and easy deployment.

Specification

10/100/1000BASE-T Copper Ports	16 auto-MDI/MDI-X ports
802.3af/802.3at PoE+ Injector Port	16
1000BASE-X SFP/mini-GBIC Slots	2
DIP Switch	Selectable operation mode: Standard, VLAN, Extend
Dimensions (W x D x H)	441.2 x 207.5 x 44.2 mm (1U height)
Enclosure	Metal
Weight	2.35 kg
Power Requirements	100~240V AC, 50/60Hz, 5A max
Power Consumption/Dissipation	Max. 262 watts / 893 BTU
Thermal Fan	2
Protection	6KV surge protection, 8KV ESD protection
LED Indicators	System Power (Green), PoE Usage 80% (Green); RJ45 Ports LNK/ACT (Green), PoE-in-Use (Amber); SFP Ports LNK/ACT (Green)
Switch Architecture	Store-and-Forward
Switch Fabric	36 Gbps / non-blocking
Switch Throughput @64 bytes	26.8 Mpps
MAC Address Table	8K entries
Jumbo Frame	9216 bytes
Flow Control	IEEE 802.3x pause frame (full duplex); back pressure (half duplex)
PoE Standard	IEEE 802.3at PoE+, backward compatible with IEEE 802.3af
PoE Power Supply Type	End-span: 1/2 (+), 3/6 (-)
PoE Power Output	54V DC, 300mA max 15.4W (802.3af); 54V DC, 600mA max 30W (802.3at)
PD Alive Check	Yes
PoE Power Budget	250 watts
Number of PDs 7W	16
Number of PDs 15.4W	16
Number of PDs 30W	8
Regulatory Compliance	FCC Part 15 Class A, CE
Standards Compliance	IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T, IEEE 802.3z Gigabit SX/LX, IEEE 802.3x flow control/back pressure, IEEE 802.3af PoE, IEEE 802.3at PoE+, IEEE 802.3az Energy-Efficient Ethernet
Operating Temperature	0 ~ 50°C
Operating Humidity	5 ~ 95% (non-condensing)
Storage Temperature	-10 ~ 70°C
Storage Humidity	5 ~ 95% (non-condensing)

Description

Safenet 16-Port 10/100/1000T 802.3at PoE + 2-Port 1000X SFP Gigabit Ethernet Switch

Key Features & Benefits:

High-Performance Network Switch: The Safenet 16-Port 10/100/1000T 802.3at PoE + 2-Port 1000X SFP Gigabit Ethernet Switch is designed for business and surveillance environments, providing high-speed data transfer and power delivery to devices.
16 Gigabit PoE+ Ports: The switch features 16 Gigabit PoE+ ports that can deliver both data and power to devices like IP cameras, access points, and VoIP phones.
2 SFP Uplink Slots: The switch also has 2 SFP uplink slots for high-speed fiber connectivity and network expansion.
Selectable Operation Mode: The DIP switch allows for selectable operation mode: Standard, VLAN, Extend.
Metal Enclosure: The switch has a metal enclosure for durability and heat dissipation.
High Power Budget: The switch has a high power budget of 250 watts, making it suitable for demanding applications.
IEEE 802.3at PoE+ Compliance: The switch is compliant with IEEE 802.3at PoE+, backward compatible with IEEE 802.3af.
6KV Surge Protection: The switch has 6KV surge protection and 8KV ESD protection for reliable operation.
Easy Installation: The switch has a simple installation process, with a user-friendly interface and clear LED indicators.
Wide Operating Temperature: The switch can operate in a wide temperature range of 0 ~ 50°C, making it suitable for various environments.
Compact Design: The switch has a compact design, making it suitable for small spaces and easy deployment.

Ideal For:

Businesses with high-speed network requirements
Surveillance environments with multiple IP cameras
Large-scale deployments with high power requirements
Network administrators seeking high-performance switches
Users requiring reliable and durable network equipment
Organizations with demanding network applications
IT professionals seeking easy-to-install and manage switches

Summary:

The Safenet 16-Port 10/100/1000T 802.3at PoE + 2-Port 1000X SFP Gigabit Ethernet Switch is a high-performance network switch designed for business and surveillance environments. It provides 16 Gigabit PoE+ ports, 2 SFP uplink slots, and a high power budget of 250 watts. The switch is compliant with IEEE 802.3at PoE+ and has 6KV surge protection and 8KV ESD protection. It is suitable for various environments and has a compact design, making it easy to deploy and manage. Available at Revolution Technology BD.
