GS-6311-48T6X L3 48-Port 10/100/1000T + 6-Port 10G SFP+ Managed Ethernet Switch
Contact us for pricing
Product Details
Key Features
High-speed networking for large businesses: The Safenet L3 48-Port 10/100/1000T + 6-Port 10G SFP+ Managed Ethernet Switch supports up to 216Gbps non-blocking switching fabric and 160.7Mpps switching throughput, making it ideal for large businesses with high-speed networking requirements.
Scalable and flexible VLAN management: The switch supports up to 4K VLAN groups, 802.1ad Q-in-Q (VLAN stacking), and GVRP for VLAN management, providing scalable and flexible VLAN management for large networks.
Advanced security features: The Safenet L3 48-Port 10/100/1000T + 6-Port 10G SFP+ Managed Ethernet Switch supports advanced security features such as access control lists, port isolation, and DHCP snooping, providing a secure and reliable network infrastructure.
High-speed data transfer: The switch supports up to 10G SFP+ interfaces, providing high-speed data transfer and minimizing network congestion.
Easy management and configuration: The Safenet L3 48-Port 10/100/1000T + 6-Port 10G SFP+ Managed Ethernet Switch supports easy management and configuration through its console port and web-based interface.
Reliable and durable design: The switch is designed with a reliable and durable design, supporting operating temperatures of 0 ~ 50 degrees C and relative humidity of 5 ~ 90% (non-condensing).
Supports IPv4 and IPv6 protocols: The Safenet L3 48-Port 10/100/1000T + 6-Port 10G SFP+ Managed Ethernet Switch supports both IPv4 and IPv6 protocols, providing a future-proof network infrastructure.
Supports advanced QoS features: The switch supports advanced QoS features such as 8 priority queues, strict priority, and Weighted Round Robin (WRR) CoS policies, providing a reliable and efficient network infrastructure.
Supports advanced security features: The Safenet L3 48-Port 10/100/1000T + 6-Port 10G SFP+ Managed Ethernet Switch supports advanced security features such as access control lists, port isolation, and DHCP snooping, providing a secure and reliable network infrastructure.
Supports high-speed data transfer: The switch supports up to 10G SFP+ interfaces, providing high-speed data transfer and minimizing network congestion.
Supports easy management and configuration: The Safenet L3 48-Port 10/100/1000T + 6-Port 10G SFP+ Managed Ethernet Switch supports easy management and configuration through its console port and web-based interface.
Supports reliable and durable design: The switch is designed with a reliable and durable design, supporting operating temperatures of 0 ~ 50 degrees C and relative humidity of 5 ~ 90% (non-condensing).
Copper Ports | 48 10/100/1000BASE-T RJ45 copper ports (ports 1 to 48) |
10G SFP+ Ports | 6 10GBASE-SR/LR SFP+ interfaces (ports 49 to 54) |
Backward compatible with | 1000BASE-SX/LX/BX SFP transceiver |
Console Port | 1 x RJ45-to-RS232 serial port (9600, 8, N, 1) |
CPU | MIPS 800MHz |
RAM | 512Mbytes |
Flash Memory | 32Mbytes |
ESD Protection | Contact ±6KV , Air ±8KV |
Surge Protection | Differential mode ±2KV , Common mode ±4KV |
Dimensions (W x D x H) | 440 x 260 x 44 mm |
Weight | 3676g |
Power Consumption | 53.7 watts/183BTU |
Power Requirements | AC 100~240V, 50/60Hz |
Fan | 1 |
LED | System: PWR (Green), SYS (Green), Ports: LNK/ACT (Green) |
Switching Specifications | Switch Architecture: Store-and-forward, Switch Fabric: 216Gbps/non-blocking, Switch Throughput: 160.7Mpps |
Address Table | 32K MAC address table with auto learning function |
ARP Table | 8K |
Routing Table | 12K |
IP Interface | 1024 |
ACL Table | 4K |
Shared Data Buffer | 16MB |
Jumbo Frame | 12KBytes |
Flow Control | Back pressure for half duplex, IEEE 802.3x pause frame for full duplex |
IPv4 Layer 3 Functions | IP Routing Protocol: Static route, RIPv1/v2, OSPFv2 |
Layer 3 Protocol | ARP, ARP Proxy, IGMP Proxy |
IPv6 Layer 3 Functions | ICMPv6, ND, DNSv6 |
Layer 2 Functions | Port Configuration: Port disable/enable, Flow control disable/enable, Bandwidth control on each port, Port loopback detect |
Port Status | Display each port's speed duplex mode, link status, flow control status and auto negotiation status |
VLAN | 802.1Q tagged VLAN, up to 4K VLAN groups, 802.1ad Q-in-Q (VLAN stacking), GVRP for VLAN management, Private VLAN Edge (PVE) supported, Protocol-based VLAN, MAC-based VLAN, IP subnet VLAN |
Bandwidth Control | TX/RX/Both |
Link Aggregation | IEEE 802.3ad LACP/static trunk, Supports 64 groups with 8 ports per trunk group |
QoS | 8 priority queues on all switch ports, Supports strict priority and Weighted Round Robin (WRR) CoS policies |
Traffic classification | IEEE 802.1p CoS/ToS, IPv4/IPv6 DSCP, Port-based WRR |
Multicast | IPv4 IGMP v1/v2/v3 snooping, IPv4 Querier mode support, IPv6 MLD v1/v2 snooping, Multicast VLAN Register (MVR) |
Security Functions | Access Control List: Supports Standard and Expanded ACL, IP-based ACL/MAC-based ACL, Time-based ACL, Up to 2K entries |
Security | Port isolation, Supports IP + MAC + port binding, Identification and filtering of L2/L3/L4 based ACL, Defend against DOS or TCP attacks, Suppression of broadcast, multicast and unknown unicast packet, DHCP Snooping, DHCP Option 82/43/60/61/67 |
Command line authority control | based on user levels |
AAA | TACACS+ and IPv4/IPv6 over RADIUS |
Authentication | IEEE 802.1x port-based network access control |
Operating Temperature | 0 ~ 50 degrees C |
Relative Humidity | 5 ~ 90% (non-condensing) |
Storage Temperature | -10 ~ 70 degrees C |
Relative Humidity | 5 ~ 90% (non-condensing) |
Description
Safenet L3 48-Port 10/100/1000T + 6-Port 10G SFP+ Managed Ethernet Switch
Key Features & Benefits:
- High-speed networking for large businesses: The Safenet L3 48-Port 10/100/1000T + 6-Port 10G SFP+ Managed Ethernet Switch supports up to 216Gbps non-blocking switching fabric and 160.7Mpps switching throughput, making it ideal for large businesses with high-speed networking requirements.
- Scalable and flexible VLAN management: The switch supports up to 4K VLAN groups, 802.1ad Q-in-Q (VLAN stacking), and GVRP for VLAN management, providing scalable and flexible VLAN management for large networks.
- Advanced security features: The Safenet L3 48-Port 10/100/1000T + 6-Port 10G SFP+ Managed Ethernet Switch supports advanced security features such as access control lists, port isolation, and DHCP snooping, providing a secure and reliable network infrastructure.
- High-speed data transfer: The switch supports up to 10G SFP+ interfaces, providing high-speed data transfer and minimizing network congestion.
- Easy management and configuration: The Safenet L3 48-Port 10/100/1000T + 6-Port 10G SFP+ Managed Ethernet Switch supports easy management and configuration through its console port and web-based interface.
- Reliable and durable design: The switch is designed with a reliable and durable design, supporting operating temperatures of 0 ~ 50 degrees C and relative humidity of 5 ~ 90% (non-condensing).
- Supports IPv4 and IPv6 protocols: The Safenet L3 48-Port 10/100/1000T + 6-Port 10G SFP+ Managed Ethernet Switch supports both IPv4 and IPv6 protocols, providing a future-proof network infrastructure.
- Supports advanced QoS features: The switch supports advanced QoS features such as 8 priority queues, strict priority, and Weighted Round Robin (WRR) CoS policies, providing a reliable and efficient network infrastructure.
- Supports advanced security features: The Safenet L3 48-Port 10/100/1000T + 6-Port 10G SFP+ Managed Ethernet Switch supports advanced security features such as access control lists, port isolation, and DHCP snooping, providing a secure and reliable network infrastructure.
- Supports high-speed data transfer: The switch supports up to 10G SFP+ interfaces, providing high-speed data transfer and minimizing network congestion.
- Supports easy management and configuration: The Safenet L3 48-Port 10/100/1000T + 6-Port 10G SFP+ Managed Ethernet Switch supports easy management and configuration through its console port and web-based interface.
- Supports reliable and durable design: The switch is designed with a reliable and durable design, supporting operating temperatures of 0 ~ 50 degrees C and relative humidity of 5 ~ 90% (non-condensing).
Ideal For:
- Large businesses with high-speed networking requirements
- Enterprises with complex network infrastructures
- Data centers with high-speed data transfer requirements
- Network administrators who require advanced security features
- Users who require a reliable and durable network infrastructure
- Users who require easy management and configuration
- Users who require support for IPv4 and IPv6 protocols
Summary:
The Safenet L3 48-Port 10/100/1000T + 6-Port 10G SFP+ Managed Ethernet Switch is a high-performance network switch designed for large businesses and enterprises with complex network infrastructures. With its advanced security features, high-speed data transfer capabilities, and reliable and durable design, this switch provides a secure and efficient network infrastructure for users who require a high level of performance and reliability. The switch is available at Revolution Technology BD and is ideal for users who require a high-performance network switch with advanced features and capabilities.
