Hikvision DS-7116HGHI-M1/T 16 Channel Lite Mini 1U DVR

৳ 6,300

Exclusive of all taxes

Genuine Product Fast Delivery Easy Returns

SPECIFICATION

Brand	Hikvision
Model	DS-7116HGHI-M1/T
Type	16 Channel Lite Mini 1U DVR
Video Input	16-ch BNC interface
IP Camera Input	2-ch (up to 18-ch total), up to 5 MP resolution
Video Compression	H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Recording Resolution	1080P Lite/720P Lite/WD1/4CIF/VGA/CIF
Frame Rate	1080P Lite/720P Lite@15 fps
Video Output	1 HDMI, 1 VGA (simultaneous output)
Audio Input	1-ch RCA + 16-ch via coaxial cable
Audio Output	1-ch RCA
Two-Way Audio	1-ch RCA
Synchronous Playback	16-ch
Network Interface	1 RJ45 10/100M Ethernet
Remote Access	Hik-Connect mobile app support
Total Bandwidth	96 Mbps
SATA Interface	1 SATA port
Max Storage	Up to 6 TB per HDD
USB Interface	2 × USB 2.0
Motion Detection	Deep learning Motion Detection 2.0
Power Supply	12 VDC, 2 A
Power Consumption	≤ 7 W (without HDD)
Working Temperature	-10°C to 55°C
Dimensions	285 × 210 × 48 mm
Weight	≤ 1.8 kg (without HDD)
Warranty	1 Year

DESCRIPTION

Hikvision DS-7116HGHI-M1/T 16 Channel Lite Mini 1U DVR

The Hikvision DS-7116HGHI-M1/T is a 16-channel surveillance DVR designed for small to medium security setups. This recorder combines video compression technology with intelligent analytics in a compact mini 1U form factor.

Intelligent Motion Detection 2.0: Powered by deep learning technology, the DVR features Motion Detection 2.0 that classifies human and vehicle targets. This reduces false alarms caused by irrelevant objects. Users can search recorded footage by object or event type for efficient forensic analysis.

Video Compression: Supporting H.265 Pro+, H.265 Pro, H.265, H.264+, and H.264 compression standards, this recorder maximizes storage efficiency while maintaining video quality. 1080P Lite recording at 15 fps per channel ensures smooth video capture.

Connectivity and Compatibility: The DVR accepts multiple video formats including HDTVI, AHD, CVI, CVBS, and IP cameras. With 16 analog channels and support for up to 18 IP cameras (up to 5 MP resolution), it offers hybrid system flexibility. Audio via coaxial cable transmits audio alongside video over standard coax lines.

Storage and Playback: One SATA interface supports up to 6 TB HDD capacity for extended recording periods. 16-channel synchronous playback allows simultaneous review of multiple camera feeds.

Monitoring and Control: Video outputs include HDMI and VGA ports supporting up to 1080P resolution. HDMI/VGA simultaneous output enables flexible viewing setups. Two USB 2.0 ports facilitate backup and mouse control.

Network Connectivity: With a 10/100 Mbps Ethernet interface and Hik-Connect support, users can access live views and playback remotely via smartphone or computer. The DVR supports remote connections and includes protocols for network integration.

Compact Design: The mini 1U chassis measures 285 × 210 × 48 mm and weighs less than 1.8 kg (without HDD), suitable for space-constrained installations. Operating reliably from -10°C to 55°C, it suits various environmental conditions.

The Hikvision DS-7116HGHI-M1/T 16 Channel Lite Mini 1U DVR delivers surveillance features, intelligent analytics, and reliable performance for businesses and homeowners. Backed by a 1-year warranty.
