LifeSmart Nature Mini L Control Panel
Contact us for pricing
Product Details
480*800 high definition 4-inch display
Works as both gateway and smart switch
Built-in speaker
Linux OS to ensure low-power and stable
operation
Supports 2.5G+5G Wi-Fi connection
Product Description
The World's First standard 120 Smart home control panel.
Nature Mini L is a smart home control panel installed at the intersection of moving paths in your home. With a full screen, edge-to-edge touchpad, it could be an in-wall light switch, a scene panel, a weather display, or even works like a thermostat. Users can control various types of smart equipment at home, switching between modes including Away, Sleep, Film, and Dining; or precisely control their curtains, adjust brightness and color of their lights, and temperatures of their air conditioner. Nature Mini L effectively enhances your smart life experience!
Features:
480*800 high definition 4-inch display
Works as both gateway and smart switch
Built-in speaker
Linux OS to ensure low-power and stable operation
16A magnetic latching relay to ensure the electrical safety
Supports voice control via Google, Alexa, and HomeKit by adding Nature Mini switches to LifeSmart Smart Station
Remote control via mobile app
Supports 2.5G+5G Wi-Fi connection
Supports multiple protocols including CoSS, Zigbee, BLE, Wi-Fi
Specification
|
Model Number |
LS218 |
|
Installation |
In-wall
concealed with 120 back box |
|
Operating
Temperature |
-5~45℃ |
|
Operating
Humidity |
5~90% |
|
Network |
Wi-Fi
2.4GHz/5GHz |
|
Interface |
Live/Neutral/Light1/Light2/Light3
wire in |
|
Screen |
4 inch |
|
Resolution |
480*800 |
|
Operation
System |
Linux |
|
Power Supply |
AC 100-240V
50/60Hz |
|
Bluetooth |
No |
|
Speaker |
Yes |
|
Radio
Protocol |
CoSS,
ZigBee,Wi-Fi 2.4GHz/5GHz |
|
Signal
Range(Open Field) |
200m(CoSS) |
|
Functions |
One-click
pairing, device management, weather display, scenes control, multi GUI skin,
device control, remote control via mobile app |
|
Support
Devices |
All CoSS
equipment, SONOS music box |
|
Controllable
Devices |
Switches,
lights, curtain motors, tubular motors, underfloor thermostats, fan coil
thermostat, air conditioner gateways, electrical appliances(via
SPOT-universal infrared controllers), etc. |
|
Color |
White/Gray |
|
Dimension |
Outside the
wall:70*120*11mm; Whole product:70*120*37mm |
|
Casing |
Flameresistant
PC |
