MikroTik Cloud Core Router CCR2004-1G-12S+2XS Ethernet Router

Genuine Product Fast Delivery Easy Returns

Key Features

High-performance networking: With 12 SFP+ ports and 2 25G SFP28 ports, this router delivers high-speed connectivity for demanding applications.

Scalable architecture: The CCR2004-1G-12S+2XS features an ARM 64-bit CPU, providing a robust and scalable architecture for growing networks.

Advanced routing capabilities: RouterOS v7 offers advanced routing features, including support for IPv6, MPLS, and OSPFv3.

Redundant power supply: With two AC inputs, this router ensures continuous operation in case of power supply failure.

Temperature monitoring: The CCR2004-1G-12S+2XS includes CPU temperature monitoring, PCB temperature monitoring, and voltage monitoring for optimal performance and reliability.

Compact design: Measuring 443 x 224 x 44 mm, this router is designed for easy deployment in a variety of environments.

Long-term reliability: With an MTBF of approximately 200,000 hours at 25°C, this router is built to last and provide reliable service over an extended period.

Compliance with international standards: The CCR2004-1G-12S+2XS meets CE, EAC, and ROHS certification requirements, ensuring compliance with international safety and environmental standards.

High-speed data transfer: This router supports 10/100/1000 Ethernet ports, enabling high-speed data transfer for demanding applications.

Flexible configuration options: With RouterOS v7, you can configure the CCR2004-1G-12S+2XS to meet the specific needs of your network, including support for IPv6, MPLS, and OSPFv3.

Easy management and monitoring: The CCR2004-1G-12S+2XS includes a user-friendly interface for easy management and monitoring of your network, ensuring optimal performance and reliability.

Robust security features: This router includes robust security features, including support for VPNs, firewalls, and intrusion detection systems, to protect your network from unauthorized access and malicious activity.

Specification

Product code	CCR2004-1G-12S+2XS
Architecture	ARM 64bit
CPU	AL32400
CPU core count	4
CPU nominal frequency	1700 MHz
CPU Threads count	4
Dimensions	443 x 224 x 44 mm
RouterOS license	6
Operating System	RouterOS v7
Size of RAM	4 GB
Storage size	128 MB
Storage type	NAND
MTBF	Approximately 200'000 hours at 25C
Tested ambient temperature	-20°C to 60°C
Number of AC inputs	2
AC input range	100-240
Max power consumption	60 W
Max power consumption without attachments	31 W
Cooling type	2 fans
Ethernet	10/100/1000 Ethernet ports
Number of Ethernet ports	1
Fiber	SFP+ ports
Number of SFP+ ports	12
Number of 25G SFP28 ports	2
Serial console port	RJ45
CPU temperature monitor	Yes
PCB temperature monitor	Yes
Voltage Monitor	Yes
Certification & Approvals	CE, EAC, ROHS
IP	20

Description

MikroTik Cloud Core Router CCR2004-1G-12S+2XS Ethernet Router

Key Features & Benefits:

High-performance networking: With 12 SFP+ ports and 2 25G SFP28 ports, this router delivers high-speed connectivity for demanding applications.
Scalable architecture: The CCR2004-1G-12S+2XS features an ARM 64-bit CPU, providing a robust and scalable architecture for growing networks.
Advanced routing capabilities: RouterOS v7 offers advanced routing features, including support for IPv6, MPLS, and OSPFv3.
Redundant power supply: With two AC inputs, this router ensures continuous operation in case of power supply failure.
Temperature monitoring: The CCR2004-1G-12S+2XS includes CPU temperature monitoring, PCB temperature monitoring, and voltage monitoring for optimal performance and reliability.
Compact design: Measuring 443 x 224 x 44 mm, this router is designed for easy deployment in a variety of environments.
Long-term reliability: With an MTBF of approximately 200,000 hours at 25°C, this router is built to last and provide reliable service over an extended period.
Compliance with international standards: The CCR2004-1G-12S+2XS meets CE, EAC, and ROHS certification requirements, ensuring compliance with international safety and environmental standards.
High-speed data transfer: This router supports 10/100/1000 Ethernet ports, enabling high-speed data transfer for demanding applications.
Flexible configuration options: With RouterOS v7, you can configure the CCR2004-1G-12S+2XS to meet the specific needs of your network, including support for IPv6, MPLS, and OSPFv3.
Easy management and monitoring: The CCR2004-1G-12S+2XS includes a user-friendly interface for easy management and monitoring of your network, ensuring optimal performance and reliability.
Robust security features: This router includes robust security features, including support for VPNs, firewalls, and intrusion detection systems, to protect your network from unauthorized access and malicious activity.

Ideal For:

Large enterprises with complex network infrastructures
Service providers requiring high-speed connectivity for demanding applications
Data centers and cloud computing environments
Telecommunications companies with high-speed networking requirements
Government agencies with secure and reliable network needs
Educational institutions with large-scale network deployments
Research and development organizations with high-speed data transfer requirements

Summary:

The MikroTik Cloud Core Router CCR2004-1G-12S+2XS is a high-performance networking solution designed for demanding applications. With its advanced routing capabilities, scalable architecture, and robust security features, this router is ideal for large enterprises, service providers, and data centers. Revolution Technology BD offers this product at a suggested price of $595.00, making it an attractive option for organizations requiring high-speed connectivity and reliable network performance.
